Transcend 110S 128GB M.2 2280 (M-Key) PCIe Gen3x4 SSD Drive

Description

PCIe SSD 110S

The PCIe SSD 110S aims at high-end applications requiring constant processing heavy workloads without any kind of lagging. Powered by 3D NAND flash memory, the Transcend 110S 128GB M.2 2280 (M-Key) PCIe Gen3x4 SSD Drive gives you not only fast transfer speeds but unmatched reliability offering next-generation performance.

Compelling Performance

Transcend’s PCIe SSD 110S follows NVMe 1.3 and utilizes the PCIe Gen3 x4 interface, as a result transmission and data receiving process occurs through four lanes simultaneously which provides?compelling performance of up to 1,700MB/s read and 1,400MB/s write.

The PCIe Interface

PCIe is a much faster interface than SATA (or Serial ATA) for connecting a host computer to solid-state storage devices over one or more lanes consisting of one transmit and one receive serial interface in each lane, meaning it can better fulfill new performance requirements.

The NVMe Standard

NVMe is a host controller interface standard designed to address the needs of enterprise and client applications that utilize PCI Express-based solid-state storage. NVMe calls for better performance vectors than AHCI (Advanced Host Controller Interface), including scalable bandwidth, increased IOPS, and low latency.

3D expansion

3D NAND flash is a type of flash memory in which the memory cells are stacked vertically in multiple layers. 3D NAND is developed to break through density limitations of the 2D planar NAND, and thus can deliver a greater level of performance and endurance.

Better Endurance, Higher Reliability

Transcend 110S 128GB M.2 2280 (M-Key) PCIe Gen3x4 SSD Drive is engineered with LDPC (Low-Density Parity Check) coding, powerful ECC algorithm to keep data secure. Manufactured with high-quality NAND flash chips, and engineered dynamic thermal throttling mechanism, the PCIe SSD 110S guarantees superior endurance and stability for high-end applications.

Specifications

• Capacity: 128GB
• Form Factor: M.2
• Flash Type: 3D NAND flash
• Interface: NVMe PCIe Gen3 x4
• Sequential R/W:
• Sequential Read/Write (ATTO) : 1,500/400 MB/s
• Sequential Read/Write (CrystalDiskMark) : 1,500/400 MB/s
• 4K Random Read/Write (IOmeter) : 90,000/90,000 IOP
• Terabytes Written (TBW) : 50 TBW
• MTBF: 1,000,000 hour(s)
• Dimension: 80 mm x 22 mm x 3.58 mm

Warranty: 3 Years
