Description
Introducing the PowerColor Red Devil AMD Radeon™ RX 9070 XT 16GB GDDR6 Graphics Card, a flagship GPU engineered for ultra-fast 4K gaming and next-gen ray tracing. Built on the AMD RDNA™ 4 architecture with 4096 stream processors and 16GB of GDDR6 memory, this card delivers blistering boost clocks up to 3060MHz. The Red Devil features a premium 12-layer PCB, DrMOS power stages, and a massive cooling array with Honeywell PTM7950 thermal compound. With support for DisplayPort 2.1, PCIe 5.0, and AMD FSR 4, it’s designed to crush modern AAA titles while keeping temperatures and noise under control. Whether you choose OC or Silent BIOS, the PowerColor Red Devil AMD Radeon™ RX 9070 XT 16GB GDDR6 Graphics Card offers uncompromising performance for enthusiasts and creators alike.
Specifications
| Feature | Details |
|---|---|
| Model | RX9070XT 16G-E/OC/WHITE |
| Memory | 16GB GDDR6, 256-bit |
| Stream Processors | 4096 |
| Game Clock | up to 2460MHz (standard) / 2520MHz (OC) |
| Boost Clock | up to 3010MHz (standard) / 3060MHz (OC) |
| Resolution Max | 7680×4320 |
| Interface | PCIe 5.0 x16 |
| Outputs | 3 x DisplayPort 2.1 (only 2x simultaneous DP2.1), 1 x HDMI 2.1 |
| Recommended PSU | 900W |
| Power Connectors | Three 8-pin PCIe |
| Dimensions | 340×132×69mm (352×149×69mm with bracket) |
| DirectX | 12 |
| OpenGL | 4.6 |
| Cooling | Vertical heatsink, 7 heatpipes, dual ball bearing fans |
| Special Features | Dual BIOS, Intelligent Fan Control, Reinforced Metal Backplate |
Unmatched Cooling with Honeywell PTM7950
The PowerColor Red Devil AMD Radeon™ RX 9070 XT 16GB GDDR6 Graphics Card incorporates Honeywell PTM7950 phase-change thermal material, which seamlessly fills microscopic gaps between the GPU die and heatsink during high-load operations. This dramatically improves thermal efficiency and sustains boost clocks longer than standard thermal pastes. Combined with a large nickel-plated copper base that covers both GPU and memory, heat is rapidly absorbed and evenly dissipated.
Vertical Heatsink and Optimized Heatpipe Arrangement
Engineers have equipped the Red Devil with a vertically oriented heatsink featuring precisely spaced fins to maximize surface area and airflow. Seven 6mm nickel-plated copper heatpipes are strategically aligned above the PCB, pulling heat away from the GPU and VRAM modules at an impressive rate. This design ensures that even under sustained gaming loads, the PowerColor Red Devil AMD Radeon™ RX 9070 XT 16GB GDDR6 Graphics Card remains cool and stable.
Dual BIOS and Intelligent Fan Control
With a simple switch, you can toggle between OC (Performance) and Silent modes, tailoring fan behavior to your preference. Intelligent Fan Control keeps fans off below 50°C and only engages them at 60°C, reducing noise during light tasks. The exclusive ring blade design with nine blades per fan and dual ball bearings ensures high static pressure, low noise, and long-term reliability, making the PowerColor Red Devil AMD Radeon™ RX 9070 XT 16GB GDDR6 Graphics Card as quiet as it is powerful.
Premium PCB and DrMOS Power Delivery
A 12-layer PCB constructed with high-thermal-conductivity material and a 2oz power layer guarantees signal integrity even at high frequencies. The power section uses a 12+1 phase DrMOS design for the GPU plus a dedicated 3+2 phase for memory, alongside conductive polymer capacitors. This reduces power loss, improves thermal stability, and enables the PowerColor Red Devil AMD Radeon™ RX 9070 XT 16GB GDDR6 Graphics Card to handle intense overclocking and transient loads without breaking a sweat.
Future-Ready Features and AMD Software Integration
Supporting PCIe 5.0 x16, DisplayPort 2.1 (with two simultaneous DP2.1 connections), and AMD Smart Access Memory, this card is built for next-generation platforms. AMD HYPR-RX one-click enables Anti-Lag, Super Resolution, and Fluid Motion Frames 2 across thousands of games. With AI-powered FSR 4 upscaling and enhanced ray tracing via RDNA™ 4, the PowerColor Red Devil AMD Radeon™ RX 9070 XT 16GB GDDR6 Graphics Card delivers immersive visuals and instant responsiveness for years to come.
