Description
Water Cooling
The Phanteks Enthoo Pro 2 RGB ATX Full Tower Casing is predestined for the installation of custom water cooling : A radiator in 480 or 420 format can be installed in the front , but the HDD cages may get in the way. It has tempered glass side panel.
Drive Bays
Numerous drives fit into a big tower like the Enthoo Pro 2 : eleven 2.5-inch and four 3.5-inch drives can be installed ex works . With optional brackets, the Enthoo Pro 2 can even accommodate up to twelve 3.5-inch drives.
Fans
Phanteks Enthoo Pro 2 RGB ATX Full Tower Casing enables the installation of up to 15 120 mm or eight 140 mm fans . There is space for four 120 or three 140 models in the front, while a 140 or 120 case fan can be installed in the rear. Three 120 mm or three 140 mm fans can be installed in the lid of the Big Tower. There is space for four 120 millimeter fans on the mainboard tray and three 120 or one 140 fan can be mounted on the bottom of the case.
RGB Lightening
The PHANTEKS Enthoo Pro 2 has integrated RGB-LED lighting of the power supply cover . Color and lighting modes can be controlled using two buttons on the I / O panel of the Big Tower or synchronized with other digitally addressable accessories using a 3-pin RGB cable. The Enthoo Pro 2 is compatible with ASUS Aura Sync , MSI Mystic Light Sync , Gigabyte RGB Fusion , ASRock Polychrome Sync and Razer Chroma .
I/O Ports
The I / O panel is hidden behind a flap in the front of the housing. In addition to the power button, four USB 3.0 ports are hidden behind the flap ,a USB 3.1 type C port and a microphone-headphone combo jack.
Compatibility
The Phanteks Enthoo Pro 2 RGB ATX Full Tower Casing is compatible with large mainboards in the form factor SSI-EEB and E-ATX. With various mounting brackets, the tower offers many possibilities to adapt the interior to your own requirements. Dual systems, dual PSU systems, numerous options for extensive water cooling circuits and vertical graphics card installation are supported ex works.
Specifications
- Case Type: Full Tower
- Front Panel:
1x USB-C 3.1
4x USB-A 3.0
1x microphone / headphones
1x power button
1x reset button
1x LED mode button
1x LED color button - Tempered Glass Panel: Yes
- Motherboard Support: SSI-EEB, E-ATX, ATX, Micro-ATX, Mini-ITX
- Color(s): Black
- Weight: 13 kg
- Dimensions: 240 x 580 x 560 mm
- Front Ports:
1x USB-C 3.1
4x USB-A 3.0
1x microphone / headphones - Expansion Slots: 8 + 3 + 3 (horizontal + vertical + vertical (second system)
- Radiator Support:
1x max. 480/420 mm (front, possibly without the HDD cages)
1x max. 360 (cover)
1x max. 140/120 mm ( Back)
1x max. 360 (bottom)
1x max. 480 mm (MB tray) - Fan Support:
3x 140 / 4x 120 mm (front)
3x 140/120 mm (cover)
1x 140/120 mm (rear)
1x 140 / 3x 120 mm (base)
4x 120 mm (MB tray) - Pre- Installed Fans: N/A
- Drive Bays:
12x 3.5 inches (internal; decoupled; 4x included, 8x optional via additionally available HDD brackets)
11x 2.5 inches (internal) - I/O Port:
1x USB-C 3.1
4x USB-A 3.0
1x microphone / headphones
1x power button
1x reset button
1x LED mode button
1x LED color button - Side Panel: Tempered Glass
- Maximum CPU Cooler Height: 195 mm
- Maximum Graphics Card Length: 503 mm
