Phanteks Enthoo Evolv X RGB ATX Mid Tower Casing (Black)

Description

Spacious

Phanteks Enthoo Evolv X RGB ATX Mid Tower Casing (Black) has a lot of place inside. It can hold graphics cards up to 435 mm long. Furthermore these cards can be installed either horizontally or vertically. For the vertical installation of a graphics card, the housing offers three slot covers leaving space behind for other expansion cards.

Radiator Support

Up to two 360 mm radiators can be installed simultaneously in this premium case in the front or roof. In the front, a radiator up to 420 mm in size can be mounted.

Fans

Up to nine fans can be controlled via the PWM fan hub. The case includes three pre-installed 140 mm fans as standard, two of which are in the front with one in the back. A total of three 120 mm fans can be mounted in the front and the top, while the rear can accommodate a 120 or 140 mm fan. Three 140 mm fans can even be installed in the front, while the top can support two 140 mm fans. The radiator support is as follows: a maximum of a 420 mm radiator (3x 140 mm) or a 360 mm radiator (3x 120 mm) can be installed in the front, while a 280 or 360 mm radiator will fit into the top of the case.

RGB LED

Phanteks Enthoo Evolv X RGB ATX Mid Tower Casing (Black) has addressable digital RGB-LEDs illuminate the area behind the front cover as well as the PSU shroud of this medium-sized tower. The LEDs can either be controlled via the front panel (Color Mode, Cycling) or via software using the motherboard. ASUS Aura Sync (addressable) and MSI Mystic Light Sync Rainbow are supported.

Mountable SSD

Up to nine SSDs can be mounted in the Phanteks Enthoo Evolv X, while three 2,5″ drives can be mounted to the cable shrouds. Three additional SSDs can be mounted behind the motherboard using the optionally available SSD brackets.

Specifications

• Type: Mid Tower
• Front Panel:
  1x USB 3.1 Type C
  2x USB 3.0
  1x Audio In/Out
  2x RGB Controller (mode, colour)
• Tempered Glass Panel: sides
• Motherboard Support: E-ATX, ATX, Micro-ATX, Mini-ITX
• Color(s): Black
• Weight: 11 kg
• Dimensions: : 240 x 520 x 510 mm
• Front Ports
  1x USB 3.1 Type C
  2x USB 3.0
  1x Audio In/Out
• Expansion Slots: 7
• Radiator Support:
  1x max. 420/360 mm (front)
  1x max. 140/120 mm (rear)
  1x max. 280/360 mm (roof)
• Fan Support:
  3x 140/120 mm (front)
  2x 140 / 3x 120 mm (roof)
  1x 140/120 mm (rear)
• Pre- Installed Fans:
  2× 140 mm (front)
  1× 140 mm (rear)
• Drive Bays:
  4x 3,5″ (internal; + 6x possible via optional additional HDD bracket)
  6x 2,5″ (internal; + 3x via optional SSD bracket behind the motherboard tray with “Drop-n-Lock”)
• I/O Port:
  1x USB 3.1 Type C
  2x USB 3.0
  1x Audio In/Out
  2x RGB Controller (mode, colour)
• Side Panel: Tempered Glass
• Maximum CPU Cooler Height: 190 mm
• Maximum Graphics Card Length: 435 mm
