Using the optional NA-SAVP5 anti-vibration pads (available in black, blue, green, red, yellow, white), the Noctua NH-U9S chromax.black 92mm CPU Cooler can be fully customized to fit popular build color schemes such as black and red or black and white.
100% RAM compatibility
With its 95x95mm footprint, the NH-U9S does not overhang the RAM slots on current Intel and most AMD mainboards. This gives the user full access to the memory modules and guarantees 100% compatibility with tall RGB modules, large heatspreaders or optional memory fans.
Compatibility with PCIe cards on mini-ITX
Many mini-ITX motherboards have the PCIe slot sitting close to the socket zone. While larger coolers that exceed this zone are likely to block the PCIe slot, the 95x95xmm sized Noctua NH-U9S chromax.black 92mm CPU Cooler provides full compatibility with PCIe cards, be it on ATX, microATX or ITX.
NF-A9 premium fan
The highly optimised features Noctua’s proprietary AAO frame as well as sophisticated aerodynamic design measures such as Flow Acceleration Channels, which allows it to further improve the renowned efficiency of Noctua’s previous 92mm models and contributes to the NH-U9S’ superior cooling performance.
- Type: Air Cooler
- Fan Speed:
Max. rotational speed (+/- 10%) 2000 RPM
Max. rotational speed with L.N.A. (+/- 10%) 1550 RPM
Min. rotational speed (PWM, +/-20%) 400 RPM
- Fan Airflow:
Max. airflow 78,9 m³/h
Max. airflow with L.N.A. 62,6 m³/h
Max. acoustical noise 22,8 dB(A)
Max. acoustical noise with L.N.A. 16,3 dB(A)
- Material: Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Input power 1,2 W
Voltage range 12 V
MTTF > 150.000 h
Height (without fan) 125 mm
Width (without fan) 95 mm
Depth (without fan) 68 mm
Height (with fan) 125 mm
Width (with fan) 95 mm
Depth (with fan) 95 mm
- Weight: Weight (with fan) 618 g
- Supported Sockets: Intel
Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1200 LGA1156, LGA1155, LGA1151, LGA1150, LGA1700
- AMD: AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required), AM4
