Description
Extra Air Extra Performance
CRYORIG’s proprietary Quad Air Inlet system features four strategically placed aerodynamic air inlet that allows for extra air intake. The additional air intake allows the QF series fan to have a higher air output volume for its fan diameter, which equals better temperatures for your CPU heatsink and more air exchanged for your system case.
Unmatched Compatibility
Focusing on providing the widest range of compatibility, the H7 utilizes an asymmetric slanted heatpipe layout to move the heatsink away from the RAM zone, Offering optimal compatibility for RAM with tall heat spreaders on both Intel 115X and AMD platforms.
The Compact Tower
The CRYORIG H7 has compact compatibility written in it’s design. Only 145mm in height the H7 is one of the smallest 120mm fan class tower heatsinks on the market. The H7 will fit in almost all mid-tower PC chassis. The H7 can deliver much needed tower grade cooling performance in tight spaces.
Heatsink Specification
Dimension ( with fan ): L98 mm x W123 mm x H145 mm
Weight ( with fan ) :711 g
Weight ( without fan ) :577 g
Heat pipes 6mm heatpipe x 3 units
Fin T = 0.4 mm ; Gap = 2.2 mm
Fin Pcs: 40 pcs
Copper Base :C1100 Pure copper nickel plated
RAM Height Limit Limitless
TDP : 140 W
Fan Specification
Model : QF120 Balance
Dimension: L120 mm x W120 mm x H25.4 mm
Weight: 134 g
Rated Speed: 300 ~ 1600 RPM ±10 %
Noise Level: 25 dBA
Air Flow: 59 CFM
Air Pressure: 1.65 mmH2O
Ampere: 0.16 A
