CRYORIG H5 Ultimate CPU Cooler

Description

Efficiency by Innovation

CRYORIG H5 Universal CPU Cooler features Hive Fin structure. This design allows for a combination of Jet Fin Acceleration and Turbulence Reduction, as well as strengthening structural strength of the fin stacks. Combined together, the Hive Fin design brings cool innovation.

Jet Fin Acceleration System

Jet Fin Acceleration System squeezes airflow and increases exhaust air speed. The increase of airflow speed in our Jet Fin Acceleration System allows heated air to leave the tower faster.

Turbulence Reduction System

Utilizing a bee hive shaped structure at the front air intake of the heatsink, lowers air turbulence and straightens out the airflow. Assisting airflow to move directly through the full length of the heatsink and carrying out hot air.

Enhanced Performance With Fine Tuned Acoustics

While boasting a full 140mm diameter 1300rpm high airflow XF140 PWM fan, CRYORIG has also fined tuned the acoustics to match performance. That’s why the XF140 140mm fan integrates several noise reduction optimizations. The XF140 features our High Precision Low Noise bearing and the detachable Acoustic Vibration Absorbers that give the fan a snugger fit while canceling vibration and noise at the same time.

Heatsink Specification:

Dimension (with fan) L110.9 x W143 x H160 ~ 168.3mm (Fan position adjustable)
Weight ( with fan )- 920 g
Weight (without fan)- 764 g
Heat pipes- 6mm heatpipe x 4 units
Fin T = 0.4 mm ; Gap = 2.8 mm
Fin Pcs- 38 pcs
Copper Base- C1100 Pure copper nickel plated
RAM Height Limit Limitless
TDP- 160 W

Fan Specification:

Model- XF140
Dimension- L140 mm x W140 mm x H25.4 mm
Weight- 156 g
Rated Speed 700 ~ 1300 RPM ±10 %
Noise Level 19 ~ 23 dBA
Air Flow- 76 CFM
Air Pressure- 1.44 mmH2O
Ampere- 0.16 A

Warranty: 3 years
