Description
Why the New Cooling Solution?
When Intel and AMD announced their latest CPUs, they all deliver remarkable performance upgrades and better productivity, it also means the functional requirement of PC equipment needs to be taken to the next level, especially the thermal performance
F-LUX Platform – Antec’s Original Cooling Solution
What is the F-LUX Platform? The definition of FLUX is Flow Luxury. The F-LUX Platform is a new industry-leading and highly efficient design by Antec featuring an advanced case structure for excellent airflow combined with 5 x 120 mm fans included. A core element of the design ethos was to enhance GPU cooling performance.
Color Your System by Built-in LED Controller
You only need the LED mode button to control all the addressable LEDs.
Or you can sync it with the motherboard to enjoy more custom light effects.
Or you can sync it with the motherboard to enjoy more custom light effects.
Go with the Flow
The front panel is designed by adopting a three-dimensional wave-shaped mesh, presenting a smoothly minimalist looking. With massive ventilation in the front, the DF700 FLUX can easily project attractive light effects and enhance the cooling.
Specification
| Case Type | ||
| Type | Mid Tower | |
| Front Panel | Power, LED Control Button, 2 x USB3.0, HD-AUDIO | |
| Tempered Glass Panel | Yes | |
| Motherboard Support | ATX , Micro-ATX, Mini-ITX | |
| External Features | ||
| Color(s) | Black | |
| Weight | 7.4Kg | |
| Dimensions | 467 x 220 x 486 mm | |
| Front Ports | 2 x USB3.0 HD-AUDIO |
|
| Expansion Slots | 7 | |
| Radiator Support | Front- 120/240/280/360mm (≤ 55mm thickness when fans are installed outside of front panel) (≤ 30mm thickness when fans are installed inside of front panel) Top-120/ 240/ 280/ 360mm Rear- 120mm |
|
| Fan Support | Front: 3 x 120mm/ 3 x 140mm Top: 3 x 120mm/ 2 x 140mm Power Supply Shroud: 2 x 120mm Rear: 1 x 120mm |
|
| Pre- Installed Fans | 3 x 120mm ARGB fans in front 1 x 120mm fan (Reverse Fan) on PSU shroud 1 x 120mm fan in Rear |
|
| Drive Bays | 3.5″/2.5″ (convertible): 3/ 2 2.5″ 3 |
|
| Additional Feature | ||
| PSU | ≤ 205mm | |
| Side Panel | Tempered Glass | |
| Clearance Space | ||
| Maximum CPU Cooler Height | ≤ 175mm | |
| Maximum Graphics Card Length | ≤ 405mm | |
