Description
Energy Efficient
5VSB adopts energy-saving chip with no-load and reduced frequency, contributing to low standby power consumption, high conversion efficiency and energy saving. Using a highly integrated PFC and PWM combo chip with power factor over 0.99, it result in more efficient conversion, more stable performance and more compatibility.
Compatibility
Rated 650W, suitable for high-end computer configuration. Aigo GP650 650W Active Power 80 plus Bronze Power Supply conforms to the Intel ATX12V specification design, supports Intel, AMD complete series of dual core platform.
Fans
It offers High efficient energy-saving silent fan. Adopt 12cm hydraulic bearing fan, mute and durable, large air flow. Built in PFC, double magnetic ring magnetic amplifier circuit, high frequency low resistance filter capacitor,to ensure that the current is pure and stable output.
Multi Function Protection
Aigo GP650 650W Active Power 80 plus Bronze Power Supply offers multi function protection circuit design, with overvoltage, overcurrent, overload, undervoltage, short-circuit, light protection functions.
Specifications
- Efficiency (Approx.): 80%
- Certification: 80+ Bronze
- Fan Size: 12cm hydraulic bearing fan, mute and durable, large air flow
- Input Voltage: 160V-264V
- Current:
+ 3.3V output current 20A
+ 5V output current 15A
+ 12V1 output current 48A
– 12V output current 0.3A
+ 5Vsb output current 2.5A - Modular Type: Non-Modular
- Total Power: 650W
- Peak Power: 850W
- AC Input: 160V-264V
- DC Output: + 3.3V output current 20A
- Main Power: 20P/ 24P motherboard
- CPU interface: P4+4
- Video card interface: (6PIN+2) *2
- SATA interface: 4
- IDE interface: 2
