Description
The TP-Link XN020-G3 300Mbps Wireless N Gigabit GPON Router is a reliable all-in-one networking solution designed for modern Fiber-to-the-Home (FTTH) internet connections. It combines a GPON modem, 300Mbps Wireless N access point and Gigabit Ethernet switch within one compact device. Supporting GPON speeds of up to 2.488Gbps downstream and 1.244Gbps upstream, this router can efficiently handle web browsing, online classes, video calls, HD streaming, large file downloads and online gaming.
Operating on the 2.4GHz wireless band, the XN020-G3 delivers Wi-Fi speeds of up to 300Mbps. Its two external 5dBi antennas provide improved wireless coverage, signal strength and connection stability. The integrated Gigabit LAN port also enables a fast and dependable wired connection for desktop computers, smart TVs, gaming consoles and other compatible devices.
For a safer network experience, it supports WPA/WPA2 encryption, NAT and SPI firewalls, access control and MAC/URL filtering. Features such as QoS, VLAN, Dynamic DNS, port forwarding, IPv4/IPv6, TR-069 and OMCI management add greater flexibility and control. With its compact design, high-speed fiber connectivity and easy management, the TP-Link XN020-G3 is an excellent networking choice for homes, small offices and ISP-managed FTTH installations.
Specification
| Specification | Details |
|---|---|
| Brand | TP-Link |
| Model | XN020-G3 |
| Router Type | Wireless N Gigabit GPON Router |
| Wireless Standards | IEEE 802.11b/g/n |
| Wireless Frequency | 2.4GHz |
| Wireless Speed | Up to 300Mbps |
| GPON Standards | ITU-T G.984.1, G.984.2, G.984.3, G.984.4 and G.988 |
| Maximum Downstream | Up to 2.488Gbps |
| Maximum Upstream | Up to 1.244Gbps |
| PON Interface | 1× SC/APC Port |
| LAN Interface | 1× 10/100/1000Mbps Gigabit LAN Port |
| Antenna | 2× External 5dBi Antennas |
| Transmission Power | Less than 20dBm at 2.4GHz |
| Wireless Security | 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK |
| Security Features | NAT Firewall, SPI Firewall, Access Control, MAC/URL Filtering and DoS Protection |
| Network Features | QoS, VLAN, Static Routing, Dynamic DNS and Port Forwarding |
| Management | OMCI, Web Configuration, CLI and TR-069 |
| IP Protocol | IPv4 and IPv6 |
| Button | Reset Button |
| Power Supply | 12V/0.6A |
| Dimensions | 115 × 106.7 × 24.3mm |
| Color | White |
| Operating Temperature | 0°C–40°C |
| Warranty | 1 Year |
TP-Link XN020-G3 300Mbps Wireless N Gigabit GPON Router
The TP-Link XN020-G3 300Mbps Wireless N Gigabit GPON Router is an all-in-one networking solution designed for Fiber-to-the-Home or FTTH connections. Combining a GPON modem, Wireless N access point and Gigabit Ethernet switch in one compact device, it provides dependable internet connectivity for homes and small offices.
High-Speed GPON Fiber Connectivity
Compliant with ITU-T G.984 and G.988 GPON standards, the XN020-G3 supports data rates of up to 2.488Gbps downstream and 1.244Gbps upstream. This high-speed fiber capability makes browsing, HD video streaming, online gaming and downloading large files faster and more convenient.
300Mbps Wireless N Performance
The router operates on the 2.4GHz band and provides a wireless speed of up to 300Mbps through IEEE 802.11b/g/n technology. It is suitable for everyday online activities, including web browsing, social networking, video calls, online classes and multimedia streaming.
Two External 5dBi Antennas
TP-Link XN020-G3 features two external 5dBi antennas that improve wireless signal transmission, coverage and stability. The 2×2 antenna configuration helps maintain a reliable Wi-Fi connection across compatible areas of a home or small workplace.
Gigabit Wired Network Connection
A built-in 10/100/1000Mbps Gigabit LAN port allows users to connect a desktop computer, smart television, gaming console or network switch through an Ethernet cable. This port offers a fast and stable wired connection for devices that require consistent network performance.
Advanced Network Security
The XN020-G3 supports WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK encryption to help prevent unauthorized access. NAT and SPI firewalls, access control, MAC/URL filtering, DoS protection, SYN flood protection and IP-MAC binding provide additional layers of network security.
Remote Management and Easy Configuration
Support for TR-069 and OMCI enables internet service providers to remotely configure, upgrade and manage the router. Web-based configuration, DHCP, QoS, Dynamic DNS, port forwarding, VLAN, static routing and IPv4/IPv6 support make the device flexible and convenient for different network requirements.
Key Features
- All-in-one GPON modem, wireless access point and Gigabit switch
- Maximum 300Mbps wireless speed on the 2.4GHz band
- Up to 2.488Gbps GPON downstream speed
- Up to 1.244Gbps GPON upstream speed
- One SC/APC optical fiber port
- One 10/100/1000Mbps Gigabit LAN port
- Two external 5dBi antennas
- QoS for efficient network traffic management
- WPA/WPA2 wireless security
- NAT and SPI firewall protection
- Supports IPv4 and IPv6
- TR-069 and OMCI remote management
- Compact and space-saving design
