Description
The TP-Link XC220-G3 AC1200 Wireless XPON Router is a versatile networking solution designed to combine fibre-optic internet connectivity and reliable dual-band Wi-Fi in one device. Its compatibility with both GPON and EPON networks makes it suitable for different fibre-based internet services.
This XPON router provides a combined wireless speed of up to 1167Mbps. The 5GHz band delivers speeds of up to 867Mbps for streaming, downloading and online gaming, while the 2.4GHz band offers up to 300Mbps for everyday browsing and smart devices.
For high-speed wired connectivity, the TP-Link XC220-G3 features two 10/100/1000Mbps Gigabit RJ45 LAN ports. A dedicated PON port allows the fibre-optic cable to connect directly to the router, helping reduce the need for multiple networking devices.
The router is equipped with two external dual-band antennas that provide stable wireless coverage across compatible spaces. It also supports WDS Bridge, WMM and wireless statistics, providing greater flexibility and improved management of the wireless network.
EasyMesh compatibility allows the XC220-G3 to work as part of a unified mesh network. Support for 802.11k/v/r helps compatible devices move smoothly between mesh points, offering seamless roaming and more consistent coverage throughout the home or office.
Security and network management features include WPA, WPA2 and WPA3 encryption, NAT firewall protection, hardware QoS, VPN pass-through and parental controls. Cloud, remote and local management options simplify network monitoring, while IPv4 and IPv6 support provides broad and future-ready compatibility.
Specification
| Specification | Details |
|---|---|
| Brand | TP-Link |
| Model | XC220-G3 |
| Router Type | Wireless XPON Router |
| Wireless Standard | IEEE 802.11ac/n/a (5GHz), IEEE 802.11b/g/n (2.4GHz) |
| Wireless Frequency | 2.4GHz and 5GHz |
| Wireless Speed | 867Mbps on 5GHz, 300Mbps on 2.4GHz |
| Combined Wi-Fi Speed | Up to 1167Mbps |
| GPON Downstream Speed | Up to 2.488Gbps |
| GPON Upstream Speed | Up to 1.244Gbps |
| EPON Downstream Speed | Up to 1.25Gbps |
| EPON Upstream Speed | Up to 1.25Gbps |
| LAN Interface | 2× 10/100/1000Mbps RJ45 LAN ports |
| Optical Interface | 1× PON port |
| Antenna | 2× external dual-band antennas |
| Buttons | WPS/Wi-Fi button, Reset button |
| Mesh Technology | EasyMesh compatible; supports 802.11k/v/r |
| Security | WPA, WPA2 and WPA3 encryption |
| Protocols | IPv4 and IPv6 |
| Power Adapter | 12V/1.0A |
| Warranty | 1 Year |
AC1200 Dual-Band Wireless Performance
The TP-Link XC220-G3 provides up to 867Mbps on the 5GHz band and up to 300Mbps on the 2.4GHz band. Users can select the appropriate band depending on their required coverage, speed and connected device.
GPON and EPON Compatibility
Support for both GPON and EPON technologies makes this router compatible with different XPON fibre networks. It delivers GPON downstream speeds of up to 2.488Gbps and upstream speeds of up to 1.244Gbps.
Dual Gigabit LAN Ports
Two Gigabit Ethernet LAN ports deliver fast wired connectivity for desktop computers, smart televisions, gaming consoles and other compatible devices. These ports support automatic 10/100/1000Mbps connection speeds.
Reliable Dual-Band Antennas
Its two external dual-band antennas are designed to deliver stable wireless connections over the 2.4GHz and 5GHz bands. They help provide reliable coverage for multiple connected devices.
EasyMesh and Seamless Roaming
The XC220-G3 is compatible with EasyMesh technology and supports 802.11k/v/r standards. This allows compatible mesh devices to create unified Wi-Fi coverage with smoother movement between access points.
Advanced Network Security
WPA/WPA2/WPA3 encryption, NAT firewall protection, parental controls and VPN pass-through help create a more secure and manageable network. Hardware QoS can also prioritise important traffic for an improved online experience.
